Description
| Model | 8300CDQ |
| Finish | Fine Textured Aluminium (Black / Silver) |
| Display | POLED 128×64 pixels 2.7″ |
| Standby Feature | Yes |
| 12V Trigger | Yes |
| CD Mechanism | Slot-Loading |
| DSD Compatible | Yes (DSD64 / DSD128 / DSD256) |
| Disc Compatibility | CD/CDR |
| DAC | ESS Sabre32 9018 chip |
| Resolution | 32 bits |
| Sampling Frequency | Optical,Coaxial, AES: 32kHz – 192kHz USB:32kHz – 384kHz(PCM) / DSD64, DSD128, DSD256 |
| Maximum Sampling Frequency | Optical,Coaxial, AES: 192kHz USB: 384kHz (PCM) / 11.2M (DSD256) |
| Output Voltage | 4.2Vrms ±0.1 (Balanced) 2.1Vrms ±0.1 (Unbalanced) |
| Output Impedance | 10Ω |
| Total Harmonic Distortion (THD) | <0.002% (1kHz, 0dB, 20Hz ~ 20kHz, A weighted) |
| Frequency Response | 20Hz – 20kHz (± 0.2dB) |
| Signal to Noise Ratio (S/N) | <-100dB A Weighted (Balanced) <-98dB A Weighted (Unbalanced) |
| Dyanmic Range (A Weighted) | >100dB (Balanced) >98dB (Unbalanced) |
| Crosstalk (@1kHz) | <-130dB (Balanced) <-120dB (Unbalanced) |
| Standby Power Consumption | <0.5W |
| Power Requirements | 240V ~ 50 – 60Hz 230V ~ 50 – 60Hz 115V ~ 50 – 60Hz 100V ~ 50 – 60Hz |
| Dimension(mm) (W x H x D) | 444 X 80 X 317 |
| Carton size(mm) ( W X H X D) | 500 x 140 x 455 |
| Weight | 6.0kg (Net) 7.5kg (Gross) |
