Description
CONTINUOUS POWER OUTPUT
100W RMS into 8 Ohms; 200W RMS into 4 Ohms
THD (UNWEIGHTED)
<0.002% 1kHz at rated power (8 Ohms); <0.02% 20Hz – 20kHz at rated power (8 Ohms)
FREQUENCY RESPONSE
<3Hz – >80kHz +/-1dB
S/N RATIO (REF 1W INTO 8 OHM)
>93 dB
CROSSTALK @ 1KHZ
< -100dB
S/N RATIO (REF FULL POWER)
>113 dB
INPUT SENSITIVITY
Input A1-A2 (unbalanced) 1.09V RMS
INPUT IMPEDANCES
Input A3 (balanced) 47k Ohm; Input A1-A2 (unbalanced) 47k Ohm
INPUTS
Balanced, Unbalanced
OUTPUTS
Speakers, Loop out
MAX POWER CONSUMPTION
1000W
STANDBY POWER CONSUMPTION
<0.5W
DIMENSIONS
150 x 460 x 405mm (5.9 x 18.1 x 15.9″)
WEIGHT
23.6kg (51.9lbs)
IN THE BOX
Edge W Power Amplifier; 1.5M Power Lead; Edge Link Cable; Edge W User Manual, Warranty Card
