Description
Model
T10
Size
365 mm x 310 mm x 88 mm (W x D x H)
Chassis Material
Aluminium alloy
Display
8.6″ LCD Touchscreen
Internal Memory
8G DDR5 + 64G eMMC
Power Supply
Custom O-Type Toroidal Transformer
System Clock
Femtosecond Clock
Audio Clock
OCXO Clock system + Phase-Locked Loop Technology
USB Ports
USB 3.0 * 2
Ethernet
RJ-45 (10/100/1000/2500Mbps)
Wi-Fi
Dual-band Wi-Fi 6 (2.4G + 5G)
SFP Fiber Network
Supports Gigabit single-mode single-fiber and single-mode dual-fiber optical modules (SFP module not included)
Playback & Decoding
Supports up to stereo DSD 512 and PCM 768kHz 32-bit
Supported Music Formats
DSD (DSF, DFF, SACD ISO Support DST up to DSD512), MP3, APE, WAV, FLAC, AIF, AIFF, AAC, NRG, CUE
Music Services
TIDAL, Qobuz, HIGHRESAUDIO, Amazon Music, IDAGIO, Calm Radio, Internet Radio, TuneIn, Radio, Paradise, Deezer, SoundCloud, Presto Music, Apple Music…
Streaming
Roon Ready, Spotify Connect Lossless, TIDAL Connect, Qobuz Connect, DLNA, and more…
Control Methods
On-screen Touch Control, Eversolo Control, and Remote Control
Supported Protocols
UPnP, NAS, SMB
Audio Characteristics
Isolated USB Audio Output
Supports up to stereo DSD512 Native and PCM 768kHz 32-bit (only compatible with DACs that support the UAC standard).
Isolated IIS Audio Output
Supports 8 output mode options. Supports up to stereo DSD512 Native and PCM 768kHz 32-bit.
Coaxial Output
Supports up to stereo PCM 192kHz 24-bit and DoP64
Optical Output
Supports up to stereo PCM 192kHz 24-bit and DoP64
AES/EBU Output
Supports up to stereo PCM 192kHz 24-bit and DoP64
External Clock Input
Supports external 10MHz / 25MHz clock input with 50Ω / 75Ω impedance
Other Information
Power Supply
AC 110~240V 50/60Hz Rated Power: 20W
Packing List
Power Cable*1, Remote Control*1, User Manual*1
Dimensions
L 365 mm x W 310 mm x H 88 mm
