Description
System Format
3-Way
Frequency Response, Free-Field (-6dB)
32 Hz – 60 kHz
Frequency Response, In-Room (-6dB)
23 Hz – 60 kHz
Sensitivity (2.83 Vrms @ 1m, Free-Field)
88 dB
Nominal Impedance
4 Ohms
Minimum Impedance (20 Hz to 20 kHz)
4.0 Ohms @ 2.5 kHz
Continuous Power Handling (RMS into 4 Ohms, Pink Noise with 6dB Crest Factor)
300 W
Recommended Amplifier Power (RMS into 4 Ohm, Music Signal)
150 – 600 W
Bass Alignment
Ported
Port Tuning Frequency
38 Hz
Crossover Frequency
LF/MF: 825 Hz
MF/HF: 3 kHz
Drive Unit Complement
2 x 6″ RDT III bass driver,
1 x 4″ RDT III mid-range driver,
1 x MPD III tweeter
External Dimensions including Trims, Terminals & Outrigger Feet & Spikes (H x W x D)
1041.6 x 368.7 x 454.9 mm (41 x 14.5 x 17.8″)
External Dimensions including Trims, Terminals & Outrigger Feet without spikes (H x W x D)
1025 x 368.7 x 454.9 mm (40.3 x 14.5 x 17.8″)
Weight (each)
35.8 kg (78 lb 14 oz)
