Description
| Transmitter Input Ports: | 1 x Stereo RCA |
| Receiver Output: | 1 x Stereo RCA |
| RF Frequency Range: | Band 1: 2400 to 2483.5 MHz Band 2: 5150 to 5250 MHz Band 3: 5725 to 5875 MHz |
| Input Level: | 2 Vrms Maximum |
| Output Level: | 1 Vrms Maximum |
| Transmission Range: | Up to 130′ / 39.6 m with Line of Sight |
| Bit Rate: | 16-Bit / 48 kHz |
| Data Rate: | 22 Mb/s |
| Frequency Response: | 6 Hz to 20 kHz, ±0.5 dB |
| Audio Latency: | <19 ms |
| THD + N: | -70 dB (10 Hz to 20 kHz) |
| SNR: | 105 dB (10 Hz to 20 kHz) |
| Crosstalk: | >75 dB @ 1 kHz |
| Power Requirements: | Transmitter: 5 VDC, 0.5 A via Micro-USB Receiver: 4.75 VDC, 0.3 A via Micro-USB |
| Dimensions: | 3.15 x 1.02 x 2.36″ / 80 x 26 x 60 mm |
| Weight: | 1.25 lb / 566.99 g |
| Package Weight: | 1.275 lb |
| Box Dimensions (LxWxH): | 10.6 x 4.3 x 2.8″ |
