Description
| Driver | 15″ front firing driver |
|---|---|
| Amplifier Class D | 1200 watt dynamic 650-watt RMS |
| Overall Frequency Response: (± 3 dB) | 23Hz – 180 Hz |
| Overall Frequency Response: (± 10 dB) | 18Hz – 220 Hz |
| Low Pass Crossover | 50 Hz to 180 Hz (12 dB/Octave) |
| Phase | 0 / 180 degrees |
| Cabinet Design | 22mm HDF 50mm front |
| Magnet Structure | Dual ferrite magnet motor |
| Woofer | 15” high excursion triple vented basket driver with carbon fiber Membrane and convex cone |
| Voice Coil | Four Layer 3″ / 76mm voice coil |
| Input | Gold plated Stereo/LFE RCA, Nickel plated XLR and High level in |
| Output | Gold plated Stereo/LFE RCA, Nickel plated XLR |
| Power Selector | Off / Auto / On |
| Finishes | Flat mat black / Flat mat white |
| Dimensions (W/H/D) (includes feet and connectors) | 48cm x 48cm x 56 cm |
| Weight (approx) | 32 kg |
| Shipping Weight (approx) | 36 kg |
