Описание
Continuous power output
(20Hz—20kHz at 0.5% THD), per channel
Both channels, 8Ω, 20Hz—20kHz
50W
Single channel, 4Ω, at 1kHz
90W
Harmonic distortion, 80% power, 8Ω at 1kHz
0.003%
Analogue Inputs
Phono (MM) cartridge
Input sensitivity at 1kHz
5mV
Input impedance
47kΩ + 100pF
Frequency response (ref. RIAA curve)
20Hz – 20kHz ± 1dB
Signal/Noise ratio (A-wtd) 50W, ref. 5mV input
80dB
Overload margin, ref. 5mV at 1kHz
21dB
Line Inputs
Nominal Sensitivity
1V
Input impedance
10kΩ
Maximum input
6Vrms
Frequency response
20Hz – 20kHz ± 0.2dB
Signal/Noise ratio (A-wtd) 50W, ref. 1V input
106dB
Digital Inputs
DAC
ESS9016K2M
Frequency response
20Hz — 20kHz ± 0.05dB
Total harmonics distortion + Noise
0.0007%
Signal/Noise ratio (A-wtd)
115dB
Supported Sample Rates (Optical)
32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz
Supported Sample Rates (Coaxial)
32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
Bit depth
16-bit – 24-bit
Pre-amplifier output
Nominal output level
630mV
Output impedance
230Ω
Headphone output
Maximum output level into 600Ω
5Vrms
Output impedance
1Ω
Load range
16Ω – 2kΩ
General
Mains voltage
110–120V or 220–240V, 50–60Hz
Maximum power consumption
350W
Dimensions W x H x D (including feet, control knob and speaker terminals)
433 x 87 x 310mm
Weight (net)
8.4kg
Weight (gross)
10.7kg
Supplied accessories
Mains leads
Remote control
2 x AAA batteries
