Описание
Body ColorOnyx Black / Stainless Steel
Body MaterialStainless Steel
Display4.1inch (720 x 1,280) Touch display
Supported Audio FormatsWAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF, DFF, DSF, MQA
MQA playbackServices(Tidal Masters), Local files, External USB, MQA-CD(ripped)
Sample ratePCM : 8kHz ~ 384kHz (8/16/24/32bits per Sample) / DSD Native: DSD64(1bit 2.8MHz), Stereo
/ DSD128(1bit 5.6MHz), Stereo / DSD256(1bit 11.2MHz), Stereo
Output LevelUnbalanced 2.0Vrms / Balanced 4.0Vrms (Condition No Load)
CPUQuad-Core
DACAKM AK4492ECB x2 (Dual DAC)
DecodingSupport up to 32bit / 384kHz Bit-to-Bit Playback
InputUSB Type-C input (for PC & MAC)
OutputsUnbalanced Out (3.5mm) / Balanced Out (2.5mm, only 4-pole supported)
Wi-Fi802.11 b/g/n (2.4GHz)
BluetoothV4.2 (A2DP, AVRCP, aptXTM HD)
Dimensions2.32 ”(59.1 mm) [W] x 4.56 ”(115.9 mm) [H] x 0.64 ”(16.5 mm) [D]
Weight10.68 oz (303 g)
Feature EnhancementsFirmware upgrades supported (OTA)
Audio Performance
Frequency Response±0.24dB (Condition: 20Hz~20kHz) Unbalanced / ±0.24dB (Condition: 20Hz~20kHz) Balanced
±1.95dB (Condition: 20Hz~70kHz) Unbalanced / ±1.94dB (Condition: 20Hz~70kHz) Balanced
Signal to Noise Ratio120dB @ 1kHz, Unbalanced / 123dB @ 1kHz, Balanced
Crosstalk-134dB @ 1kHz, Unbalanced / -138dB @ 1kHz, Balanced
THD+N0.0006% @ 1kHz, Unbalanced / 0.0006% @ 1kHz, Balanced
IMD SMPTE0.0003% 800Hz 10kHz(4:1) Unbalanced / 0.0004% 800Hz 10kHz(4:1) Balanced
Output ImpedanceUnbalanced Out 3.5mm (1.8ohm) / Balanced out 2.5mm (1.9ohm)
Clock source
Reference Clock Jitter70ps(Typ)
Battery
Capacity3,150mAh 3.7V Li-Polymer Battery
Continuous Playback TimeUp to 8.5 hours (Standard — MUSIC: FLAC, 16-bit/44.1kHz, Unbalanced, Volume 80, EQ OFF, LCD OFF)
Charge TimeAbout 4.5 hours (Standard — 5V/2A Charging)
Memory
Built-in Memory128GB [NAND]
External MemorymicroSD (Max. 1TB) x1
OS
Supported OSWindows 7,8,10 (32/64bit), MAC OS X 10.7 and up
