Описание
| Model | 8300A |
| General description | Integrated Amplifier |
| Design philosophy and core technology | Dual Mono Power Amp Design |
| Display | OLED 128×64 pixels 2.7″ |
| Controls | Logarithmic Ladder Volume Design |
| Finish | Fine Textured Aluminium (Black / Silver) |
| Standby Features | Yes |
| 12V Trigger | Yes |
| Phono | Yes (MM/MC) |
| Balanced XLR Input | Yes |
| Pre-amplifier Section | |
| Inputs | CD, Video, Tuner, Aux 1, Aux 2, XLR (Balanced) & Phono |
| Outputs | 2 x RCA |
| Input sensitivity (Phono RIAA) | 50K // 100pF |
| Input impedance (line inputs) | 50K // 100pF |
| Input impedance (phono inputs) | 47K // 100pF (MM), 100R // 1.5nF (MC) |
| Output voltage | 2.3V max. (< 0.02% THD) |
| Output impedance | 120Ω |
| Frequency response (Line) | +/- 0.1dB (10Hz — 20kHz) +/- 3.0dB (1Hz — 100kHz) |
| Frequency response (Phono RIAA) | +/- 1.0dB (20Hz — 20kHz) |
| Channel Imbalance | < 0.2dB (10Hz — 20kHz) |
| Total harmonic distortion (THD) Line | <0.001% |
| Total harmonic distortion (THD) Phono | <0.002% |
| Signal-to-noise ratio (Line) | > 107dB >109dB(A-weighted) |
| Signal-to-noise ratio Phono (MM) | > 73dB > 78dB(A-weighted) |
| Signal-to-noise ratio Phono (MC) | > 68dB > 73dB(A-weighted) |
| Crosstalk | < 80dB (L-> R & R->L @10kHz) |
| Power amplifier Section | |
| Gain | 29dB (20Hz-20kHz) |
| Input Sensitivity | 840mV (Power Out = 70W into 8Ω) |
| Input impedance | 15K // 100pF |
| Rated max power output THD < 1% | 2 x 75W RMS (8Ω) , 2 x 115W (4Ω) (Vmains = 230V , THD < 1%) |
| Peak output current | +/- 15A |
| Frequency response | +/- 0.1dB (10Hz – 20kHz) +/- 3.0dB (1Hz – 100kHz) |
| Channel Imbalance | < 0.2dB (10Hz – 20kHz) |
| Total harmonic distortion (THD) | <0.002% (Power Out= 50W @ 1kHz, BW = 20Hz – 20kHz) |
| Signal-to-noise ratio | > 107dB (BW = 20 – 20kHz ) >109dB(A-weighted BW = 20 – 20kHz) |
| Damping factor | >100 (8Ω Load @ 1kHz) |
| Inputs | 1 x RCA |
| Outputs | Speaker Binding Post Terminals |
| Dimensions | 80 x 444 x 330.3mm |
| Net weight | 7.8kg |
