| Analog Audio Output Supported Formats |
PCM up to 32bit/768kHz, DSD up to 512 (DSD512 converted to PCM by FPGA) |
| Analog Audio Outputs |
Balanced XLR, 4.0Vrms Output, Unbalanced RCA, 2.0Vrms Output |
| Control Software |
Aurender Conductor for iPad, iPhone and Android |
| CPU |
Intel Low Power Quad-Core |
| D/A Convertor |
AKM4490 (dual-mono design), MQA Full-Decoder Certified |
| Digital Audio Outputs |
USB Audio Class 2.0 x 1 |
| Dimensions & Weight |
16.9″ (W) x 3.8″ (H) x 14.0″ (D), 26.2 lbs, 430mm (W) x 96mm (H) x 355mm (D), 11.9 kg |
| Front Panel Display |
6.9” 1280 x 480 IPS Color LCD |
| Gigabit Ethernet |
Double-Isolated x 1 |
| I/O Ports |
2 x USB 3.0 (rear) |
| IR Remote Control |
Supplied |
| Main Clock |
TCXO Based Precision Jitter Reducing Clock |
| Material |
Machined Aluminum Chassis |
| Power Consumption |
Play (29W), Peak (42W), Standby (7W) |
| Power Supply |
Full-Linear |
| SPDIF Digital Inputs |
Coaxial x 1, Optical x 1 |
| SSD for System and Cache |
240GB NVMe |
| Storage (optional-user installed) |
2 bays accommodating 2.5” HDDs or SSDs (15mm height max) |
| Streaming Support |
Tidal, Qobuz, Spotify Connect and Internet Radio |
| System Memory |
8GB |
| UPS |
Yes (Super Capacitor based) |
| USB Audio Output Supported Formats |
PCM up to 32bit/768kHz, DSD: DoP up to 256, Native DSD up to 512 |
| Volume Control |
Variable or Fixed Output |
