Описание
Frequency Response 20 Hz – 20 kHz ± 2 dB
Frequency Range 12 Hz – 32 kHz
Channel Balance within 1 dB @ 1 kHz
Channel Separation better than 30 dB @ 1 kHz
Sensitivity 0.35 mV ± 1 dB, 1 kHz @ 5 cm/sec
Static Compliance 28 mm/N
Trackability 90 um (@ 315 Hz)
Equivalent tip mass 0.34 mg
Vertical Tracking Angle 20 °
Stylus Profile: Vital line-contact
Stylus Radius 35 x 8 µm (0.3 mil)
Stylus Type Factory Replaceable
Load Resistance 100 Ω
Load Capacitance 100 – 500 pF
Internal Inductance 3.5 µH
Internal Resistance 3.8 Ω
Cartridge Mass 7.7 g
Cartridge Mass (inc. fixings) 8.5 g (without stylus cover)
Fixing Centres 0.5 » (12.7 mm)
Playing Weight 1.5 — 2.0 g (1.75 g nom.)
