Описание
Design
Two-way closed box
Drive units
Uni-Q Driver Array:
HF: 25 mm (1 in.) vented aluminium dome with MAT
LF/MF: 130 mm (5.25 in.) aluminium cone
HF: 25 mm (1 in.) vented aluminium dome with MAT
LF/MF: 130 mm (5.25 in.) aluminium cone
Frequency range (-6dB)
96 Hz — 20 kHz
Typical in-room bass response (-6dB)
90 Hz
Frequency response (±3dB)
105 Hz — 20kHz
Crossover frequency
2.7 kHz
Amplifier requirements
10 — 150 W
Sensitivity (2.83V/1m)
86 dB
Harmonic distortion (90dB, 1m)
<2% 145 Hz and above
<1% 170 Hz — 20 kHz
<1% 170 Hz — 20 kHz
Maximum output
109 dB
Impedance
4 Ω (min. 3.2 Ω)
Weight *
4.5 kg (9.9 lbs.)
Dimension (H x W x D) with terminal *
176 x 180 x 259 mm (6.9 x 7.1 x 10.2 in.)
Finishes
Satin Black / Satin White / Walnut
