ELECTRONIC SPECIFICATIONS
-
- Number of Channels
2 - Total Harmonic Distortion
0.08% - Frequency Response
+0, -0.5dB from 20Hz to 20kHz
+0, -3dB from 15Hz to 100kHz - Maximum Volts Out (Balanced / Unbalanced)
16V RMS / 8V RMS - Sensitivity High Level (Balanced / Unbalanced)
900mV / 450mV - Sensitivity Phono (Moving Coil)
0.45mV - Sensitivity Phono (Moving Magnet)
4.5mV - Signal To Noise Ratio (High Level)
95dB - Signal To Noise Ratio (Moving Coil)
75dB - Signal To Noise Ratio (Moving Magnet)
80dB - Voltage Gain (High Level)
15dB - Voltage Gain (Moving Coil)
75dB - Voltage Gain (Moving Magnet)
55dB - Input Impedance (Balanced / Unbalanced)
44K ohm, 22K ohm
- Number of Channels
CONNECTIVITY
-
- Balanced Input
1 - Unbalanced Input
2 - Phono Input Moving Coil
1 (adjustable) - Phono Input Moving Magnet
1 (adjustable) - Upgradeable Digital Audio Module
Yes: DA2 can be installed - Digital Coaxial Input
0 - Digital Optical Input
0 - Digital MCT (DIN) Input
0 - Digital USB Input
0 - HDMI (ARC) Input
0 - Digital AES/EBU Input
0 - Balanced Fixed Output
0 - Balanced Variable Output
1 - Unbalanced Fixed Output
0 - Unbalanced Variable Output
2 - Headphone Output
1/4″ High Drive - Input Level Match
Yes, +/- 6dB - Home Theater PassThru
Yes - Unbalanced Analog Connector Type
Standard - Service Port
1
- Balanced Input
CONTROL
-
- Tone Controls
Bass and Treble - Tone Bypass and Input Assign
Yes - RS232 Control Input
Yes - Power Control Output
1 Main, 2 Trigger - Rear Panel Data Port
2 - Rear Panel IR Sensor Input
Yes
- Tone Controls
GENERAL SPECIFICATIONS
-
- Multi-Chassis or Single
Single - Output Meters
No - Vacuum Tube or Solid State
Vacuum Tube - Power Consumption (On)
50 Watts
- Multi-Chassis or Single
WEIGHTS & DIMENSIONS
-
- Unit Dimensions (W x H x D)
12-9/32″ (31.2cm) x 7-5/8″ (19.4cm) x 16-1/4″ (41.3cm) - Unit Weight
18 lbs (8.2 kg) - Shipping Weight
25 lbs (11.3 kg)
