Описание
ELECTRONIC SPECIFICATIONS
-
- Number of Channels
2 - Total Harmonic Distortion
0.0015% (at 2V Output) - Frequency Response
+/-0.5dB from 4Hz to 20kHz
+0.5/-3dB from 4Hz to 68kHz - Maximum Volts Out (Balanced / Unbalanced)
16V RMS / 8V RMS - Sensitivity High Level (Balanced / Unbalanced)
N/A - Sensitivity Phono (Moving Coil)
N/A - Sensitivity Phono (Moving Magnet)
N/A - Signal To Noise Ratio (High Level)
111dB - Signal To Noise Ratio (Moving Coil)
N/A - Signal To Noise Ratio (Moving Magnet)
N/A - Voltage Gain (High Level)
N/A - Voltage Gain (Moving Coil)
N/A - Voltage Gain (Moving Magnet)
N/A - Input Impedance (Balanced / Unbalanced)
N/A
- Number of Channels
CONNECTIVITY
-
- Balanced Input
0 - Unbalanced Input
0 - Phono Input Moving Coil
0 - Phono Input Moving Magnet
0 - Upgradeable Digital Audio Module
No - Digital Coaxial Input
3 (2 RCA and 1 BNC) - Digital Optical Input
3 - Digital MCT (DIN) Input
1 - Digital USB Input
1 - HDMI (ARC) Input
0 - Digital AES/EBU Input
1 - Balanced Fixed Output
1 - Balanced Variable Output
2 - Unbalanced Fixed Output
1 - Unbalanced Variable Output
2 - Headphone Output
1/4″ High Drive with Headphone Crossfeed Director (HXD®) - Input Level Match
No - Home Theater PassThru
No - Unbalanced Analog Connector Type
Premium gold-plated solid brass - Service Port
1
- Balanced Input
CONTROL
-
- Tone Controls
No - Tone Bypass and Input Assign
No - RS232 Control Input
Yes - Power Control Output
4 Trigger - Rear Panel Data Port
4 - Rear Panel IR Sensor Input
Yes
- Tone Controls
GENERAL SPECIFICATIONS
-
- Multi-Chassis or Single
Single - Output Meters
Yes - Vacuum Tube or Solid State
Solid State - Power Consumption (On)
30 watts
- Multi-Chassis or Single
WEIGHTS & DIMENSIONS
-
- Unit Dimensions (W x H x D)
17.5″ (44.45cm) x 6″ (15.24cm) x 19″ (48.3cm) - Unit Weight
26 lbs (11.8 kg) - Shipping Weight
41 lbs (18.6 kg)
- Unit Dimensions (W x H x D)
