Описание
-
ELECTRONIC SPECIFICATIONS
- Power Output per Channel
300 Watts @ 2, 4 or 8 Ohms - Number of Channels
2 - Total Harmonic Distortion
0.005% - S/N below rated output
Balanced: 120dB
Unbalanced: 118dB - Dynamic Headroom
2.3dB - Damping Factor
>40 Wideband - Rated Power Band
20Hz to 20kHz - Frequency Response
+0, -0.25dB from 20Hz to 20,000Hz
+0, -3.0dB from 10Hz to 100,000Hz
CONTROL
- Remote Power Control
Yes - Multi-Channel DB25 Cable
N/A
CONNECTIVITY
- Speaker Binding Post Type
Patented Solid Cinch™ Speaker Binding Posts
GENERAL SPECIFICATIONS
- Circuit Configuration
Push-Pull Complementary - Circuit Design
Solid State - Mono Bridge
No - Mono Parallel
No - Output Type
Autoformer™ - Meters
Yes - Meter Light Switch
Yes - Balanced Input
2 - Front Panel
Glass - Illumination
Direct LED - Chassis Style
Polished stainless steel & black painted steel
WEIGHTS & DIMENSIONS
- Unit Dimensions (W x H x D)
17-1/2″ (44.45cm) x 9-7/16″ (23.97cm) (including feet) x 22″ (55.88cm) (including front panel, handles and cables) - Unit Weight
105 lbs (47.63 kg) - Shipping Weight
138 lbs (62.59 kg)
