ELECTRONIC SPECIFICATIONS
-
- Power Output per Channel
Solid State section: 600 Watts @ 2, 4 or 8 Ohms
Vacuum Tube section: 300 Watts @ 2, 4 or 8 Ohms - Number of Channels
1 - Total Harmonic Distortion
Solid State section: 0.005% maximum harmonic distortion at any power level from 250 milliwatts to rated power, 20Hz to 20,000Hz
Vacuum Tube section: 0.5% maximum harmonic distortion at any power level from 250 milliwatts to rated power, 20Hz to 20,000Hz - S/N below rated output
Solid State section: 122dB
Vacuum Tube section: 112dB - Dynamic Headroom
Solid State section: 2.5dB
Vacuum Tube section: 1.2dB - Damping Factor
Solid State section: >40
Vacuum Tube section: >18 - Rated Power Band
Solid State section: 20Hz to 20kHz
Vacuum Tube section: 20Hz to 20kHz - Frequency Response
Solid State section:
+0, -0.25dB from 20Hz to 20,000Hz
+0, -3dB from 10Hz to 100,000Hz
Vacuum Tube section:
+0, -0.5dB from 20Hz to 20,000Hz
+0, -3dB from 10Hz to 70,000Hz
- Power Output per Channel
CONTROL
-
- Remote Power Control
Yes - Multi-Channel DB25 Cable
N/A
- Remote Power Control
CONNECTIVITY
-
- Speaker Binding Post Type
Patented Solid Cinch™ Speaker Binding Posts
- Speaker Binding Post Type
GENERAL SPECIFICATIONS
-
- Circuit Configuration
Solid State section: Quad Balanced
Vacuum Tube section: Unity Coupled - Circuit Design
Solid State and Vacuum Tube - Mono Bridge
No - Mono Parallel
No - Output Type
Solid State section: Autoformer™
Vacuum Tube section: Unity Coupled Output Transformer - Meters
DualView™ Power Output Meter - Meter Light Switch
Yes - Balanced Input
3 (1 Solid State, 1 Vacuum Tube, 1 Composite) - Front Panel
Glass - Illumination
Direct LED - Chassis Style
Polished stainless steel & black painted steel
- Circuit Configuration
WEIGHTS & DIMENSIONS
-
- Unit Dimensions (W x H x D)
17-17/32″ (44.5cm) x 13-3/8″ (34cm) x 29-17/32″ (75cm) - Unit Weight
180 lbs (81.6 kg) - Shipping Weight
200 lbs (90.7 kg)
- Unit Dimensions (W x H x D)
