HEADPHONE OUTPUT SPECIFICATIONS
- Headphone Power Output
500mW - Headphone Output Impedance
32-100 Ohms
100-250 Ohms
250-600 Ohms
600-1,000 Ohms
ELECTRONIC SPECIFICATIONS
- Power Output per Channel
N/A - Speaker Impedance
N/A - Rated Power Band
20Hz to 20kHz - Total Harmonic Distortion
0.5% maximum harmonic distortion at any power level from 250 milliwatts to rated power, 20Hz to 20,000Hz
<0.20% at 1W, 20Hz to 20,000Hz - Intermodulation Distortion
0.04% Typical
0.4% Maximum - Dynamic Headroom
1.5dB - Frequency Response
+0, -0.5dB from 20Hz to 20,000Hz - Sensitivity (Unbalanced)
1.0 Vrms - Sensitivity (Balanced)
2.0 Vrms - Maximum Input Signal (Unbalanced)
8V - Maximum Input Signal (Balanced)
16V - Signal To Noise Ratio
94dB - Input Impedance (Balanced / Unbalanced)
20K/10K - Damping Factor
>150 - Preamplifier Output
N/A - Preamplifier Output Impedance
N/A - Voltage Gain
12dB at 32 Ohms
17dB at 100 Ohms
21dB at 250 Ohms
25dB at 600 Ohms - Power Guard
No
CONNECTIVITY
- Headphone Output
One pair of 3-pin balanced XLR connectors for dedicated Left and Right balanced output;
One 4-pin balanced XLR connector for balanced stereo output;
One 1/4″ stereo headphone jack - Balanced Input
1 - Unbalanced Input
1 - Digital AES/EBU Input
0 - Digital Coaxial Input
0 - Digital Optical Input
0 - Digital MCT (DIN) Input
0 - Digital USB Input
0 - Preamplifier Output
0
DIGITAL AUDIO SPECIFICATIONS
- Digital AES/EDU Input Sample Rate
N/A - Digital Coaxial Input Sample Rate
N/A - Digital Optical Input Sample Rate
N/A - Digital MCT (DIN) Input Sample Rate
N/A - Digital USB Input Sample Rate
N/A
CONTROL
- Tone Controls
No - Power Control Input
1 - Power Control Output
1
GENERAL SPECIFICATIONS
- Output Meters
No - Vacuum Tube or Solid State
Vacuum Tube - Power Requirement
120V 50/60Hz, 1.5A - Standby Power Requirement
<0.5 Watts - Output Type
Unity Coupled Output Transformer
WEIGHTS & DIMENSIONS
- Unit Dimensions (W x H x D)
6-1/8″ (15.6cm) x 5-3/4″ (14.6cm) x 9-1/8″ (23.2cm) - Unit Weight
10.5 lbs (4.8 kg) - Shipping Weight
12 lbs (5.5 kg)
