Описание
- AUDIO SPECIFICATIONS
- Number of Channels
2 - Audio Formats Decoded
MP3, WMA, AAC, LPCM, SACD, Multi-format DTS (including DTS-HD Master Audio), Multi-format Dolby (including Dolby TrueHD) - Output Level
4.0Vrms Balanced
2.0Vrms Unbalanced - Output Impedance
600 ohms Balanced
600 ohms Unbalanced - Blu-ray and DVD Frequency Response
4Hz to 22,000Hz (48kHz Sampling, Linear Audio)
4Hz to 44,000Hz (96kHz Sampling, Linear Audio)
4Hz to 88,000Hz (192kHz Sampling, Linear Audio) - SACD Frequency Response
4Hz to 40,000Hz - CD Frequency Response
4Hz to 20,000Hz - Signal To Noise Ratio
115dB - Dynamic Range
110dB - Total Harmonic Distortion
0.002% - Channel Separation
Better than 110dB (1,000Hz)
- Number of Channels
- DIGITAL AUDIO SPECIFICATIONS
- Digital Coaxial Output
0.5V p-p/75 ohms - Digital Optical Output
-15dBm to -21dBm - Digital Signal Format Sampling Frequencies
44.1kHz, 48.0kHz, 96.0kHz and 192.0kHz
- Digital Coaxial Output
- VIDEO SPECIFICATIONS
- Signal System
NTSC/PAL - Region Code
A, 1 - Component Video Output Level
N/A - Composite Video Output Level
N/A - Supports 3D Playback
Yes
- Signal System
- CONNECTIVITY
- Stereo Outputs Unbalanced
1 - Stereo Outputs Balanced
1 - Multi-Channel Outputs Unbalanced
0 - HDMI Output
1 - Digital Coaxial Output
1 - Digital Optical Output
1 - Component Output
0 - Composite Output
0 - Ethernet
1 - USB
3 (1 front panel, 2 rear panel) - Diagnostic Output
1
- Stereo Outputs Unbalanced
- CONTROL
- Rear Panel IR Sensor Input
Yes - Rear Panel Data Input
Yes - Power Control Input
Yes - Power Control Output
Yes - RS232 Control Input
Yes
- Rear Panel IR Sensor Input
- GENERAL SPECIFICATIONS
- Disc Formats
Blu-ray, DVD, CD, SACD, DVD-Audio - Disc Capacity
1 - Laser Beam Wavelength
630nm/810nm - Laser Power
CLASS I - Standby Power Requirement
<0.5 watt
- Disc Formats
- WEIGHTS & DIMENSIONS
- Unit Dimensions (W x H x D)
17-1/2″ (44.45cm) x 6″ (15.24cm) x 13-1/2″ (34.3cm) - Unit Weight
19.5 lbs (8.8 kg) - Shipping Weight
35.9 lbs (16.3 kg)
- Unit Dimensions (W x H x D)
