Описание
System Format
2-Way
Frequency Response, In-Room (-6dB)
42 Hz — 30 kHz
Sensitivity (2.83 Vrms @ 1m, Free-Field)
88 dB
Sensitivity (2.83 Vrms @ 1m, Installed)
N/A
Nominal Impedance
8 Ohms
Minimum Impedance (20 Hz to 20 kHz)
4.7 Ohms @ 17 kHz
Maximum Peak SPL (AES75, Z-weighted)
112 dB
Continuous Power Handling (CTA 426-B)
100 W
Recommended Amplifier Power (RMS, Music Signal)
50 — 200 W into 4 Ohms
30 — 100 W into 8 Ohms
Bass Alignment
Ported
Port Tuning Frequency
47 Hz
Crossover Frequency
LF/HF: 3.0 kHz
Drive Unit Complement
1 x 6″ C-CAM bass mid driver
1 x 25mm C-CAM Gold Dome tweeter
External Dimensions with all accessories fitted (H x W x D)
465 x 300 x 135 mm (185/16 x 1113/16 x 55/16″)
Packed Dimensions (H x W x D)
573 x 402 x 240 mm (229/16 x 1513/16 x 97/16″)
Weight (each)
7 kg (15 lb 7 oz)
Sold As
Single
Warranty
5 years
