Описание
System Format
3 Way — 4 Driver
Frequency Response (-6 dB — IEC 268-13)
28 Hz — 100 kHz
Sensitivity (1W@1M)
90 dB
Maximum SPL
117.8 dBA (pair)
Nominal Impedance
4 ohms (4.2 ohms min. @ 111 Hz)
Power Handling (RMS)
300 W
Recommended Amplifier Requirements
100 — 300 W
Cabinet Design
Two HiVe II ports
Sealed mid-range TLE enclosure
Drive Unit Complement
2 x 8″ RDT II long-throw bass drivers
1 x 4″ RDT II mid-range driver
1 x MPD high frequency transducer
Crossover Frequency
MF/HF: 3.4 kHz
LF/MF: 500 Hz
External Dimensions (Including Plinth and Terminals) (H x W x D))
1075.4 x 432.4 x 517.83 mm (425/16 x 17 x 203/8″)
External Dimensions (Including Feet and Spikes (H x W x D))
1111.7 x 432.4 x 517.83 mm (433/4 x 17 x 203/8″)
Weight (each)
54.52 kg (120 lb 3 oz)
Sold As
Pair
