Описание
System Format
3 — way
Frequency Response, In-room (-6dB)
65 Hz — 35 kHz
Sensitivity (2.83v @ 1m)
88.5 dB
Nominal Impedance
8 Ohms
Minimum Impedance
3.9 Ohms @ 170 Hz
Maximum SPL (single, free-field)
110 dB
Power Handling (RMS)
200 W
Recommended Amplifier Requirements
80 — 200 W
Crossover Frequency
L.F: 650 Hz
M.F/ H.F: 3.3 kHz
Port Tuning Frequency
N/A
Bass Alignment
Sealed cabinet
Drive Unit Complement
2 x 5 1/4″ C-CAM RST II bass driver
1 x 3″ C-CAM RST II mid-range driver
1 x 1″ (25 mm) C-CAM Gold Dome tweeter with UD Waveguide II
External Dimensions (Including Grille and Terminals (H x W x D))
206 x 481 x 272 mm (87/64 x 1816/64 x 1045/64″)
External Dimensions (including Outrigger Feet and Spikes (H x W x D))
N/A
Weight (each)
10.6 kg (23 lb 6 oz)
Sold As
Single Unit
