Channel balance at 1 kHz 1 dB
Output voltage at 1 kHz, 5cm/sec 0.3 mV
Channel separation at 1 kHz 20 dB
Frequency response 20 Hz — 20 kHz 2/-1 dB
Tracking ability at 315 Hz 70 μm
Compliance, dynamic, lateral 8 μm/mN
Stylus type Nude Elliptical
Stylus tip radius r/R 8/18 μm
Tracking force range 3.0-5.0 g (30-50 mN)
Tracking force, recommended 4.00 g (40 mN)
Tracking angle 20º
Internal impedance, DC resistance 3 ohm
Recommended load impedance 10 ohm
Coil wire material Silver, 6-nines
Cartridge body material Ground wood and resin composite
Cartridge colour Shiny black
Cartridge weight 28 gram
