Описание
Channel balance at 1 kHz 1.5 dB
Output voltage at 1 kHz, 5cm/sec 0.5 mV
Channel separation at 1 kHz 23 dB
Frequency response 20 Hz — 20 kHz 2 dB
Tracking ability at 315 Hz 60 µm
Compliance, dynamic, lateral 8 µm/mN
Stylus type Nude Elliptical
Stylus tip radius r/R 8/18 µm
Tracking force range 3.0-4.0 g (30-40 mN)
Tracking force, recommended 3.5 g (35 mN)
Tracking angle 20°
Internal impedance, DC resistance 2 ohm
Recommended load impedance 10 — 50 ohm
Coil wire material High Purity Copper (OFC)
Cartridge body material Ground wood and resin composite
Cartridge colour Shiny Black
Cartridge weight 28 g
