Описание
DAC: 2x ESS9038Q2M (dual mono – 32bit/768kHz/DSD512)
Digital inputs: 1 x USB 2.0 Audio 32/768 + DoP and Native-DSD up to DSD512, 1 x HDMI I2S for CD Box RS2 T, 2 x S/PDIF optical 24/192, 1 x S/PDIF coaxial 24/192, 1x AES/EBU balanced 24/192
MQA support: full MQA unfolding by hardware
Output impedance: 180 Ohm solid state, 220 Ohm tube
Analog outputs: Pre-out (XLR & RCA)
THD+N (20Hz – 20kHz): < 0.0008% solid state/0.001% tube @ 2V RMS, 1 kHz
Masterclock output: 16,9344MHz for CD Box RS2 T
Output buffer: discrete and balanced, tube and solid state
Tubes: 4 x 6922EH
Power supply: 20V/3A DC, 110-240V/50, 60 Hz
Power consumption: max. 1,2A DC, <0,5W in standby
Dimensions W x H x D (with sockets): 206 x 72 x 222 mm
Weight: 1520 g without power supply
