Описание
Moving Magnet
Mass & Dimension
6.5g, 17.2 x 18.8 x 29mm (WxHxD)
Stylus
0.3 x 0.7mil Elliptical
Cantilever
Aluminium Pipe
Coils
High-Purity Copper
Internal Impedance
1,130Ω
Load Impedance
47kΩ
Frequency Response
15Hz – 25kHz
Output
5.0mV
Channel Separation
25dB @ 1kHz
Channel Balance
1.5dB @ 1kHz
Compliance
10×10-6cm/dyn @ 100Hz
Capacitance
100pF – 200pF
Vertical Tracking Angle
25°
Tracking Force Range
1.8g – 2.2g
Recommended Tracking Force
2.0g
Replacement Stylus Unit
RS Rainier, RS Olympia or RS Moonstone (Interchangeable)
