Mechanical data
Number of leads, totally (specified) 7 (+, — and drain x two channels + EarthLink) pieces
Lead area 0.24 mm2
Number of strands per lead 19 pieces
Strand dimension Ø 0.127 mm
Strand material Tin plated Oxygen-free 5N Copper
Di-electric (Insulation) PE
Shield Carbon/Nylon shield
Jacket Age and heat resistant PVC
Connectors Supra RCA-SC chuck lock strain relief
Outer dimension per lead Ø 6.0 mm
Cable weight (without connectors) 48 g/m
Electrical properties
Resistance 72 Ω/km
Capacitance 52 pF/m
Velocity factor 0.66 x C (speed of light)
