StereoPlus / Aavik I-180
1Aavik I-180Aavik I-180Aavik I-180Aavik I-180
Aavik I-180
2
3
4
5

Aavik I-180

6500.00

Integretājs pastiprinātājs.

Description

Connections

Line in:

Line inputs: 5 single ended – RCA
Gain Line 1-4: 5-15dB; max input 4,5V RMS
Gain Line 5: 1-11dB; max input 6,5V RMS
Input impedance: 10Kohm

Pre out:

Pre out: 1 single ended – RCA
Max output: 7,5Vms
Distortion, line stage: <0,005% (THD at 1kHz, 1V input)
Output impedance: 50 ohm

Power out:

Speaker terminals: Spade connectors or 4mm banana plugs



Amplifier Section

Volume Control: 76 dB – 1dB steps
Output:

2×300 w, 8 ohm
2 x 600 w, 4 ohm

Distortion (THD+N): <0,006% (1-100W, 1 kHz, 8 ohm)
IMD: <0,002% (1-100W, 4 ohm)
TIM: <0,008% (1-100W, 4 ohm)



Aavik Noise Reduction

Active Tesla Coils: 36
Active Square Tesla Coils: 96
Dither circuitry: 5
Anti Aerial Resonance Coils: 4



Power consumption

Standby: <0.5W
Idle: <50W



Dimensions and weight

L x W x H: 400 x 384 x 102 mm
Weight: 8.8 kg
