Description
Features
– Plays all disc formats, including SACD, CD-A, CD-R and CD-RW
– Supports audio file formats including FLAC, WAV, AIFF, OGG, MP3, AAC and WMA
– USB input
– Superb 32-bit DAC built in
– Streaming through the music life app
– Total harmonic distortion + noise = 0.002%
Specifications
Analogue Audio Output
– Digital to Analogue Conversion: ESS9038 32-bit/192kHz Delta-Sigma DAC
– Signal/Noise Ratio (Awtd): 118dB unbalanced, 122db balanced
– Harmonic Distortion (1kHz): <0.0008%
– Frequency response: 10Hz – 20kHz ± 0.5dB
– Output Level (0dB): 2.2Vrms unbalanced, 4.5Vrms balanced
– Output Impedance: 47Ω unbalanced, 600Ω balanced
– Minimum Recommended Load: 5kΩ
– RMS Jitter < 20 psec
Digital Inputs supported sample rates
– Optical 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz
– Coaxial 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
– Bit depth 16-bit – 32-bit
Digital Interfaces
– USB USB 2.0 High Speed (480Mbps)
– Ethernet 10/100Mbps
– Wireless 802.11b/g/n
General
– Mains voltage 110–240V, 50–60Hz
– Maximum power consumption 20W
– Standby power consumption network standby power consumption: 0.4W (auto standby after time set by user – see page EN-12)
– Dimensions (W x H x D)(including feet and control knob) 433x87x283mm
– Weight (net) 5.3kg
– Weight (gross) 7.3kg
Supplied accessories
– Mains leads
– Remote control
– 2 x AAA batteries
– Wi-Fi Antenna
