Description
DAC
ESS ES9028Q2M
USB Audio Input
USB Type B conforms to USB Audio 2.0
Digital Audio Inputs
HDMI eARC, USB Drive, Bluetooth (5.1), S/PDIF Coaxial, TOSLINK Optical
Anaogue Audio Inputs
Balanced XLR and unbalanced RCA analogue
Digital Audio Outputs
S/PDIF Coaxial and TOSLINK Optical
Compatibility
TOSLINK optical: 16/24bit 32-96kHz PCM, DoP64 S/PDIF coaxial: 16/24bit 32-192kHz PCM, DoP64 UPnP: up to 32bit, 768kHz Local USB media: PCM up to 32-bit 768kHz, DSD up to x512 USB audio: PCM up to 32-bit 768kHz, DSD up to x512 Bluetooth: SBC, AAC AirPlay 2, Chromecast built-in, Internet Radio, Spotify Connect, TIDAL Connect, MQA, Qobuz, Deezer, Roon Ready.
Audio Formats
ALAC, WAV, FLAC, AIFF, DSD (x512), WMA, MP3, AAC, HE AAC, AAC+, OGG Vorbis
Ethernet
10/100Mbit
Wi-fi
IEEE 802.11 ac (2.4GHz / 5GHz)
Max Power Consumption
30W
Standby Power Consumption
<0.5W (eco), <2W (network standby)
Dimensions
430 x 85 x 305mm (16.9 x 3.4 x 12.2″)
Weight
3.55Kg (7.83lbs)
What’s in the box?
CXN100 SE, mains lead, control bus cable, antenna x2, quick start guide, safety sheet, registration card
