| Touch Screen: |
6.5″ LCD Full HD |
| RAM: |
4Go DDR4 |
| ROM: |
64Go eMMC |
| DAC: |
ES9039 PRO |
| USB interface: |
XMOS XU316 |
| Op-amp Chip: |
OPA1612 |
| Power Supply: |
Dual linear power supplies: high-quality, low-noise |
| SSD Support: |
M.2 NVME 3.0 protocol 2280 up to 4TB x2 (SSD sold separately) |
| Inputs: |
- 1x Ethernet RJ45 (10 / 100 / 1000Mbps)
- 1x Balanced XLR
- 1x Single-ended RCA
- 1x HDMI ARC
- 2x SPDIF Coaxial
- 1x USB-B
- 2x Optical Toslink
|
| Outputs: |
- 1x Balanced XLR
- 1x Single-ended RCA
- 1x SPDIF Coaxial
- 1x Optical Toslink
- 2x USB-A
- 2x Subwoofer output
|
| SFP Fiber Ethernet: |
Supports external “single-mode single-fiber” and “single-mode dual-fiber” SFP modules (SFP modules to be purchased separately) |
| 12V Trigger: |
Yes |
| Wireless Connectivity: |
- 2.4G+5G dual-band WiFi
- Bluetooth 5.0
|
| Suppported Sample Rates: |
- USB: PCM up to 32bit 768kHz, DSD up to DSD512
- Optical / Coaxial: PCM up to 24bit 192kHz, DSD DoP64
- HDMI ARC: PCM up to 24bit 192kHz
|
| Supported Streaming Services: |
Tidal, Qobuz, Amazon Music, Deezer, Apple Music, Highresaudio, Paradise Radio |
| Supported Transmission Protocols: |
WebDAV, UPnP, AirPlay, DLNA, Tidal Connect, Roon Ready |
| Supported Bluetooth Codecs: |
SBC, AAC, aptX, aptX HD, aptX LL, LDAC |
| Compatible OS (USB): |
Windows 10 / 11, Android, iOS |
| RCA Output: |
- Output level: 2.1Vrms
- Frequency Response: 20Hz – 20kHz (±0.15dB)
- THD+N: < 0.00009% (-121dB) @ A-wt
- Crosstalk: > -122dB
- Dynamic Range: > 129dB
- SNR: > 129dB
|
| XLR Output: |
- Output Level: 4.2Vrms
- Frequency Response: 20Hz – 20kHz (±0.15dB)
- THD+N: < 0.000078% (-122dB) @ No-wt
- Crosstalk: > -123dB
- Dynamic Range: > 130dB
- SNR: > 130dB
|
| Power Supply: |
110-240VAC 50 / 60Hz |
| Rated Power: |
30W |
| Dimensions: |
16.9″ x 12.2″ x 4.6″ (430 x 310 x 117mm) |
| Color: |
Black |
