Description
Frequency Response 20 Hz-20 kHz +/- 3 dB
Channel Balance within 2 dB @ 1 kHz
Channel Separation better than 25 dB @ 1 kHz
Sensitivity 6.5 mV +/-1.5 dB, 1 kHz @ 5 cm/sec
Static Compliance 24 mm/N (lat); 16 mm/N (vert)
Equivalent tip mass 0.45 mg
Vertical Tracking Angle 24 °
Stylus Profile Gyger S
Stylus Type Replaceable
Load Resistance 47 kΩ
Load Capacitance 150-200 pF
Internal Inductance 570 mH
Internal Resistance 660 Ω
Cartridge Mass 6.3 g
Cartridge Mass (inc. fixings) 7.6 g
Fixing Centre 0.5″ (12.7 mm)
Playing Weight 1.5 – 2.0 g (1.7 g nom.)
Replacement stylus 1042 – D42
