Description
- Three Balanced XLR inputs each channel.
- One Single Ended RCA input each channel
- One Balanced XLR output each channel
- Input load Impedance MM: 47K Ohm, MC: from 20 Ohm to 1600 Ohm in selected steps
- Input load Capacitance MM: 0pF to 608pF in selected steps, MC: 0pF, 220pF or 440pF.
- Output impedance: 50 Ohm
- Bandwidth: RIAA +/-0,1dB
- Total Power Supply Capacity, both unit’s: 74.000uF each stereo channel
- Gain: MM +38dB or +48dB @ 1kHz, MC: +58dB or +68 dB @ 1kHz
- S/N Unweighted 20-20kHz: MM: 86dB @ 10mv, MC: 70dB @ 0,5mv
- S/N A-weighted 20-20kHz: MM: 90dB @ 10mv, MC: 74dB @ 0,5mv
- Channel Separation: Infinite
- MENU-controlled functions:
- Moving Magnet (MM) or Moving Coil (MC) selection
- Additional +10dB Gain option, MM and MC
- Moving Coil load impedance and capacitance
- Moving Magnet load capacitance
- Input Naming
- Display Intensity: (100%-75%-50%-25% and Auto Dim ON/OFF)
- Restore Settings
- Infra-Red source
- MENU Exit
- Outer dimensions, W x D x H:
- SIREN unit:
- 480mm x 236mm x 455mm 18.9in x 9.3in x 17.9in
- PSU unit:
- 480mm x 236mm x 440mm 18.9in x 9.3in x 17.3in
- Net weight:
- SIREN unit:
- 30,4kg – 67lb
- PSU unit:
- 38kg – 83.8lb
- Shipping weight:
- Two crates; each 59 x 57 x 38 cm, respectively 45kg – 99lb and 52kg – 114,4lb
- Note: Specifications can be changed without notice.
