Description
System Format
2-Way
Frequency Response (-6 dB)
83 – 25,000 Hz (Free field)
66 – 30,000 Hz (In room)
Sensitivity (2.83v @ 1m)
88 dB
Nominal Impedance
8 ohms
Minimum Impedance
4.3 ohms
Maximum SPL
109 dBA (each)
Power Handling (RMS)
120 W
Recommended Amplifier Requirements
30 — 120 W
Bass Alignment
Sealed cabinet
Crossover Frequency
2,700 Hz
Drive Unit Complement
2 x 51/2″ C-CAM mid-range driver
1 x 25 mm C-CAM Gold Dome tweeter with UD Waveguide
External Dimensions (Including Grille and Terminals (H x W x D))
166 x 451 x 225 mm (69/16 x 173/4 x 88/16″)
External Dimensions (including Outrigger Feet and Spikes (H x W x D))
N/A
Weight (each)
7 kg (15 lb 7 oz)
Sold As
Single Unit
