StereoPlus / Ortofon Cadenza Bronze
Ortofon Cadenza Bronze

Ortofon Cadenza Bronze

2499.00

MC tipa vinila plašu atskaņotāja galviņa

Description

Output voltage at 1000 Hz, 5cm/sec. – 0.4 mV
Channel balance at 1 kHz – < 1 dB
Channel separation at 1 kHz – > 24 dB
Channel separation at 15 kHz – > 20 dB
Frequency response 20 Hz – 20 kHz – +/-1.5
Tracking ability at 315Hz at recommended tracking force *) – 80 µm
Compliance, dynamic, lateral – 12 µm/mN
Stylus type – Nude Ortofon Replicant on conical alu cantilever
Stylus tip radius – r/R 5/100 µm
Tracking force range – 2.2-2.7 g (22-27 mN)
Tracking force, recommended – 2.5 g (25 mN)
*) Typical value

Tracking angle – 23°
Internal impedance, DC resistance – 5 Ohm
Recommended load impedance – 50-200 Ohm
Cartridge body material – Stainless steel / Aluminium
Cartridge colour – Bronze/Black
Cartridge weight – 10.7 gram
