Description
Output voltage at 1 kHz, 5cm/sec 3 mV
Frequency response 20 Hz – 20 kHz 2/- 1 dB
Tracking ability at 315 Hz 70 µm
Compliance, dynamic, lateral 12 µm/mN
Stylus type Spherical
Stylus tip radius R 25 µm
Tracking force range 3.0-5.0 g (30-50 mN)
Tracking force, recommended 4.0 g (40 mN)
Tracking angle 20°
Internal impedance, DC resistance 100 ohm
Recommended load impedance 47 kohm
Coil wire material High Purity Copper (OFC)
Cartridge body material Ground wood and resin composite
Cartridge colour Black matte
Cartridge weight 28 g
