Description
| Tube assembly: | 2x E88CC / 6922 |
| Input impedance: | stepless 10-1000 Ohms, fix 47 kOhms |
| Capacitance: | 50 / 150 / 300 / 400 pF |
| Gain (+6dB using XLR Out): | 40 / 45 / 50 / 55 / 60 / 65 dB |
| Output voltage typically: | 500 mV/1kHz at 5mV/1kHz (at 40dB) |
| Signal-to-noise ratio: | >87dBV – ‚A‘ weighted |
| THD: | < 0,03% |
| RIAA curve accuracy: | +/- 0,5dB/20Hz – 20kHz |
| Subsonic filter: | at 20Hz with 18dB/octave |
| Input: | 1x 5-pin mini XLR / 1x pair XLR / 1x pair RCA phono |
| Output: | 1x pair RCA, 1x pair XLR |
| Power supply: | 18V/1000mA DC |
| Power consumption: | max 750 mA DC / < 0,5 watt standby |
| Dimensions W x H x D: | 206 x 70 x 194 mm |
| Weight: | 1560g (without power supply) |
