Description
| Available Color | Black, Silver |
| Power Input | IEC (AC) 100-240V, 50/60Hz (DC) 12V/1A (5.5mm x 2.5mm connector) |
| Ethernet Port | Gold-plated 1GbE RJ45 port x 8 |
| Interface | Clock input switch x 1 (external/internal) – BNC interface 25MHz external Word Clock – Silent Angle specialized TCXO clock moduleLAN port LED indicator switch x 1 – Control the on/off status of LAN port LED Grounding Port x 1 |
| LED Indicator | AC Power LED (green) x 1 DC Power LED (green) x 1 LAN Port Status LED x 8 – Light on when linked; Flash when it’s active – Green: 1000Mbps; Amber: 100Mbps |
| Temperature | Operating: 32 ~ 86 °F (0 ~ 30 °C) Storage: -4 ~ 158 °F (-20 ~ 70 °C) |
| Humidity | Operating: 10% ~ 90% RH (non-condensing) Storage: 5% ~ 95% RH (non-condensing) |
| Dimensions | 17.29 (W) x 2.49 (H) x 9.95 (D) inch 439 (W) x 63 (H) x 250 (D) mm |
| Weight | 14.34 lbs / 6.4 kg |
