Description
Specifications
| Basic HW Specs | |
| SoC / Memory | RK3588 (Octa-core) 2.4Ghz, 8G/32G |
| Casing | 430mm full size (8T) |
| Dimension & Weight | 430 x 130 x 355 mm, 19.25kg |
| Front display | 8.8″ 1920×480 IPS LCD |
| NVMe | 500GB PCI3.0x |
| Power | Full Linear Toroidal |
| Clock | OCXO & FPGA high precision |
| DAC | AKM4499EX Quad (2x/CH) |
| Headphone Amp | Yes |
| Ethernet | 100/1000 (Gigabit) |
| Buttons/ Jog | 1x Power/ 7x Buttons/ 1x Volume Jog |
| Streaming Inputs | |
| Summary | Google Cast/ BT/ ARC/ SPDIF-in/ USB-in/ SSD |
| Google Cast builtin | 1x HW module |
| BT | AptX-Lossless |
| TV-ARC | Yes |
| 2.5″ tray | 2x 2.5″ tray for SSD/HDD |
| Digital Inputs | |
| Coaxial/ Optical/ USB | 1x/ 1x/ 1x |
| AES-EBU IN | 1x |
| I2S IN | 1x |
| USB IN | 1x |
| Clock Input | |
| External Clock IN | 10Mhz (50 ohm) BNC |
| Analog/ Digital Outputs | |
| Coaxial OUT | 1x |
| USB OUT | 1x |
| Analog OUT | 1x XLR, 1x RCA |
| Other IO/ Headphone Outputs | |
| Headphone Output | 3.5mm/ 6.3mm/ 4.4mm Sony |
| USB 3.0 | 2x for external storage |
| 12V Trigger OUT | 1x for external equipment |
| 12V Trigger IN | Yes |
| Software/ Decoding Specs/ Remote | |
| OS | Debian 11 (booting time < 25 seconds) |
| Streaming Support | Google Cast / Tidal Connect/ Spotify Connect |
| Music Client | Aurender Conductor |
| Decoding spec | PCM 768Khz/ DSD512 |
| Remote (BLE) | Basic IR Remote + Rotary BLE Remote |
