Description
Specifications
| Standards Compliance | IEEE802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3z |
| Data Transfer Rate | LAN1-6 : 100Mbps/1000Mbps, SFP1-SFP2 : 100Mbps/1000Mbps |
| Number of Port(Filter) | LAN Ports : LAN1-2(2x), LAN3-LAN6(7x), SFP Ports : 2 |
| Connector Type | RJ-45 8pin, SFP |
| Transmission Distance | 100m(Max) |
| LED On/Off | Toggle Switch |
| OCXO Spec | Frequency Stability : < 0.005ppm |
| Master Clock In Spec | 10MHz, 0.7Vrms, BNC(50ohm) |
| Input Voltage | 110V / 220V (Fuse: 2A, 5mm x 20mm, Slow-blow) |
| Operating Temperature | 10°C to 35°C |
| Size | 430 x 355 x 56 mm (unit only), With Foot(68 mm) 16.9 x 14.0 x 2.2 inch (unit only) With Foot(2.7 inch) |
| Weight | 8.0kg(17.6lbs) |
| Power Consumption | Stand by : 3.1W Power On : Start Warm-up 26W(Max) State Lock: 20W(Max) |
