Description
| Input impedance: 330 kΩ |
| Frequency resp. (in. filter active):0.5 – 220 kHz |
| Frequency resp. (in. filter dis.): 0.5 – 1.1 MHz |
| Voltage gain (mono, bal. input): 29 dB (x28) |
| Input-referred noise (20-20kHz): < 2 μV |
| SNR (ref. 1W/8Ω load, 20-20 kHz): 95 dB |
| SNR (ref. full power out, 20-20 kHz): 120 dB |
| Slew-rate (input filter disabled): 140 V/μs |
| DC output voltage: < 5 mV |
| THD+N: 0.0006 % |
| IMD: 0.001 % |
| Damping factor (8Ω load): > 1000 |
| Power consumption standby: < 0.5W |
| Protection: DC, overload, temperature |
RATED OUTPUT POWER MONO: |
| 8Ω load: 300 W |
| 4Ω load: 600 W |
| 2Ω load: 1000 W |
WEIGHT & DIMENSIONS: |
| Weight: 30 kg – 66.13 lbs |
| Width: 212 mm – 8.34 inches |
| Depth: 488 mm – 19.21 inches |
| Height: 292 mm – 11.49 inches |
| *Features and specifications are subject to change without further notice. |
