Description
| Display: | 8.8″ IPS |
| Chassis Material: | Aluminium alloy |
| Main Processor: | DCP8568 |
| DAC: | Left Channel: AK4191 + AK4499, Right Channel: AK4191 + AK4499 |
| Audio Processor: | Multi-core USB audio processor |
| OPA Chip: | OPA1612 |
| Power: | Triple ultra-low noise linear power supplies |
| Bluetooth Audio Input: | Qualcomm QCC5125 Bluetooth module, Bluetooth version: BT5.0; supports SBC/AAC Bluetooth audio protocols |
| USB-B Audio Input: | Compatible with Windows 10 and above, macOS, Android, and iOS; supports up to Stereo DSD512 / PCM 768kHz 32Bit |
| IIS Input: | Supports 8 mode configurations, up to Stereo DSD512 / PCM 768kHz 32Bit |
| AES/EBU Input: | Up to Stereo PCM 192KHz/24Bit / DSD64 DoP |
| Optical Audio Inputs *2: | Up to Stereo PCM 192KHz/24Bit / DSD64 DoP |
| Coaxial Audio Inputs *2: | Up to Stereo PCM 192KHz/24Bit / DSD64 DoP |
| ARC Input: | Up to Stereo PCM 192KHz/24Bit |
| Analog Audio Inputs: | XLR (Balanced), RCA |
| Pre-out: | Pre-out: XLR (Balanced), RCA; Headphone out: 6.35mm single-ended |
| External Clock Input: | Supports 10M/25M clock inputs with 50Ω or 75Ω impedance |
| Recommended Headphone Impedance: | 16–300Ω (Low Gain: 16–32Ω / High Gain: 32–300Ω) |
| Power Supply: | AC 100~240V 50/60Hz |
| USB Ports: | USB2.0*1（only for firmware upgrade） |
| Control Methods: | Touchscreen control, remote control, mobile App control |
| Rated Power Consumption: | 32W |
| Dimensions: | 265mm (L) × 310mm (W) × 78mm (H) |
