Description
Technical Specifications
Power output: 2x150W into 8 Ohms @ 1kHz 1% THD , 100/120/230V AC
Minimum load: 2 ohms
Analog inputs: 1x Balanced (XLR), 2x Unbalanced (RCA)
Phono input: 1 x Unbalanced (RCA) for Moving Magnet (MM)
Digital outputs: 1x Coaxial S/PDIF – 24/192
Digital inputs: 1x Coaxial (RCA) S/PDIF – 24/192, 2x Optical S/PDIF – 24/96, 1x USB B- 24/192, 1x USB A 2.0 – USB Drives (10,000 songs), 1x Network – 24/192
Line level outputs: 1x Unbalanced variable (RCA), 1x Unbalanced fixed (RCA)
Streaming: Spotify Connect (Lossless), Tidal Connect, Qobuz Connect, Apple AirPlay, Google Cast, airable Internet Radio and Podcast, UPnP
Streaming formats: MP3, WAV, FLAC, ALAC, AIFF, AAC, PCM, Ogg
Smart Home: Control4, Crestron Home, Crestron SIMPL
Frequency response: 5Hz-100kHz
Signal-to-noise ratio: More than 100dB
Crosstalk: Less than -100dB
Distortion: Less than 0.01% @ 50W 8 Ohms 1kHz
Intermodulation: Less than 0.01% (19kHz + 20kHz)
Damping factor: More than 4000 (main power output stage)
Dimensions/weight: 43 x 41 x 12 cm (WxDxH), 13.6 kg
Dimensions/weight US: 17 x 16.2 x 4.7″ (WxDxH), 30 lbs
