Description
Type 3-Way bookshelf loudspeaker pair with floor stands
Low Frequency Driver 12-inch (300mm) pure pulp cone woofer (JW300SW-8)
Mid Frequency Driver 5.25-inch (130mm) pure pulp cone midrange (JM125PC-8)
High Frequency Driver 1-inch (25mm) Titanium dome tweeter (JT025TI2-4)
Recommended Amplifier Power 25 – 200W RMS
Impedance 4 Ohm
Loudspeaker Sensitivity 90 dB/1W/1m
Frequency Response 40 Hz – 40 kHz (-6 dB)
Crossover Frequencies 450 Hz, 3.5 kHz
Enclosure Type Front-ported bookshelf
Controls High-frequency and Mid-frequency L-pad attenuators
Product Dimensions (with Stands) 32.4-in H x 15.4-in W x 14.6-in D(823.6mm x 390.4mm x 362.4mm) each
Input Type Dual sets of gold-plated binding posts
Product Weight (with Stands) 77.4 lbs. (35.1 kg) each
Shipping Weight (in Crate) 284.3 lbs. (129.2 kg)
Shipping Units of Measure Pair with stands
Warranty 5 Years
Documents & Downloads
The latest owner’s manuals, quick start guides, and documents.
Owners Manual (Multilingual)
Multilingual – 33 MB
Quick Start Guide (Multilingual)
Multilingual – 9 MB
Spec Sheet (English)
English – 918 KB
