Description
| FREQUENCY RESPONSE: | 75 Hz – 20 kHz (–10 dB @ 49 Hz) |
| POWER HANDLING: | AES: 112 watts (30V) 40 Hz – 10 kHz, IEC: 190 watts (33.5V) |
| MAXIMUM SPL: | 121.3 dB Continuous, 127.3 dB Peak |
| SENSITIVITY: | 98.5 dB @ 2.83V |
| COVERAGE: | Horizontal: 90° +/– 20° 2 kHz – 18 kHz, Vertical: 60° +20°/–15° 1.6 kHz – 20 kHz |
| DIRECTIVITY INDEX (DI): | 8 dB +/- 1 dB 2.2 kHz – 20 kHz |
| DIRECTIVITY FACTOR (Q): | 6.3 2 kHz – 20 kHz |
| NOMINAL IMPEDANCE: | 8 ohms, minimum 4.5 ohms @ 230 Hz |
| CROSSOVER FREQUENCY: | 1.77 kHz 12 dB/Octave LF 18 dB/Octave HF |
| COMPONENTS: | One K-81-ST 8″ woofer, One K-103-TI 1” titanium compression driver on a K-702 horn |
| INPUT CONNECTION: | Four point barrier strip |
| BRACKET SCREW PATTERN: | 4 screw: 2.75” (6.9cm) x 5” (12.7cm) |
| INCLUDED SCREWS: | (4) 1.125” (2.86cm) 1/4-20 x 1.25 UNC 2A, (4) .75” (1.9cm) 1/4-20 x .75 UNC 2A |
| ENCLOSURE MATERIAL: | ABS + 10% glass |
| GRILLE: | Powder-coated steel |
| HEIGHT: | 18.7” (47.5cm) |
| WIDTH: | Top: 14.7” (37.3cm), Bottom: 13” (33cm) |
| DEPTH | Top: 7.2” (18.3cm), Bottom: 4.7” (11.9cm) |
| WEIGHT | 20 lbs (9.07kg) |
| FINISHES | Black |
