Description
System Format
2.5-Way
Frequency Response, In-Room (-6dB)
34 Hz — 30 kHz
Sensitivity (2.83 Vrms @ 1m, Free-Field)
88 dB
Sensitivity (2.83 Vrms @ 1m, Installed)
N/A
Nominal Impedance
8 Ohms
Minimum Impedance (20 Hz to 20 kHz)
4.4 Ohms @ 38 Hz
Maximum Peak SPL (AES75, Z-weighted)
118 dB
Continuous Power Handling (CTA 426-B)
150 W
Recommended Amplifier Power (RMS, Music Signal)
75 – 300 W into 4 Ohms
40 – 150 W into 8 Ohms
Bass Alignment
Ported – HiVe II
Port Tuning Frequency
38 Hz
Crossover Frequency
LF/MF: 470 Hz
MF/HF: 2.6 kHz
Drive Unit Complement
2 x 6″ C-CAM bass mid driver
1 x 25mm C-CAM Gold Dome tweeter
External Dimensions with all accessories fitted (H x W x D)
1005 x 269 x 392 mm (399/16 x 105/8 x 157/16″)
Packed Dimensions (H x W x D)
1098 x 427 x 320 mm (431/4 x 1613/16 x 125/8″)
Weight (each)
15.6 kg (34 lb 6 oz)
Sold As
Pair
Warranty
5 years
