Description
System Format
3-Way
Frequency Response, In-Room (-6dB)
66 Hz – 35 kHz
Sensitivity (2.83 Vrms @ 1m, Free-Field)
89 dB
Sensitivity (2.83 Vrms @ 1m, Installed)
N/A
Nominal Impedance
8 Ohms
Minimum Impedance (20Hz to 20kHz)
4.0 Ohms @ 160 Hz
Maximum Peak SPL (AES75, Z-weighted)
120 dB
Continuous Power Handling (CTA 426-B)
200 W
Recommended Amplifier Power (RMS, Music Signal)
100 – 400 W into 4 Ohms
50 – 200 W into 8 Ohms
Bass Alignment
Sealed
Port Tuning Frequency
N/A
Crossover Frequency
LF/MF: 620 Hz
MF/HF: 3.0 kHz
Drive Unit Complement
2 x 6″ C-CAM RST III bass drivers
1 x 3″ C-CAM RST III bass-range driver
1 x 25 mm C-CAM Gold Dome tweeter
Finishes
High Gloss Black
European Walnut
Satin White
External Dimensions with all accessories fitted (H x W x D)
205 x 511 x 272 mm (81/16 x 201/8 x 1011/16“)
Weight (each)
11.7 kg (25 lb 13 oz)
Sold As
Single
Warranty
5 years
