Amplifier |
|
Channels: |
5.2.2 |
Power Output per Channel: |
1-Channel Driven:165 W at 6 Ohms / 1 kHz / 10% THD2-Channel Driven:80 W at 8 Ohms / 20 Hz to 20 kHz / 0.08% THD |
Dynamic Power per Channel: |
160 W at 3 Ohms (Front)125 W at 4 Ohms (Front)85 W at 8 Ohms (Front) |
Frequency Response: |
10 Hz to 100 kHz +1 dB (Direct, Pure Mode) |
THD+N: |
0.08% (20 Hz to 20 kHz) |
Speaker Impedance: |
4 to 16 Ohms |
Tone Control: |
Bass (20 Hz): ±10.0 dBTreble (20 kHz): ±10.0 dB |
Audio Processing |
|
DTS Compatibility: |
DTS Virtual:X, DTS-HD Master Audio, DTS:X |
Dolby Compatibility: |
Dolby Atmos, Dolby TrueHD |
Auro 3D Support: |
No |
Upmixing Technology: |
DTS Virtual:X, Dolby Atmos Height Virtualization Technology |
Video |
|
HDR Compatibility: |
HDR10+ |
Pass-Through Support: |
4K120p |
Upscaling: |
None |
GUI: |
Yes |
Connectivity |
|
Rear A/V Inputs: |
4 x HDMI 2.13 x RCA1 x Digital Coaxial1 x Optical TOSLINK |
Rear A/V Outputs: |
2 x HDMI2 x RCA Subwoofer Pre-Out1 x Stereo RCA Zone B Pre-/Line-Out |
Front I/O: |
1 x 1/4″ / 6.35 mm Headphone Output1 x 1/8″ / 3.5 mm Setup Mic Input |
Other Rear I/O: |
1 x RJ45 (Ethernet) Input/Output1 x USB Type-A (Power) Output1 x FM Coaxial F-Type Input1 x AM Block Input |
Speaker Connectors: |
5 x Spring Clip Pairs (Center, Height, Rear Surround)2 x Binding Post Pairs (Front) |
HDCP Support: |
Version 2.3 |
HDMI Compression Modes: |
4K120AB / 8K60B |
Audio Return Channel (ARC): |
ARC, eARC |
HDMI CEC: |
Yes |
Media Card Slot: |
None |
Bi-Amp Capability: |
Yes |
Input Impedance: |
Line: 32 Kilohms |
Input Sensitivity: |
Line: 200 mVrms |
Rated Output / Impedance: |
Zone B Line-Out: 1 Vrms / 2.2 KilohmsZone B Line-Out: 200 mVrms / 2.2 Kilohms |
Signal to Noise Ratio: |
Line: 106 dB (IHF-A) |
Wireless Connectivity |
|
Wi-Fi: |
Wi-Fi 5 (802.11ac); Dual-Band (2.4 & 5 GHz) |
Supported Audio Codecs: |
AAC, SBC, aptX, aptX HD |
Wireless Audio Protocols: |
AirPlay 2, Chromecast built-in, DTS Play-Fi, Roon Ready |
Control |
|
External Control Support: |
Android/iOS Control App |
Virtual Assistant: |
Works with Alexa, Works with Google Assistant |
Tuner Section |
|
Tuner Type: |
AM, FM |
Number of Tuner Presets: |
40 Stations |
Radio Frequencies: |
AM: 530 to 1710 kHzFM: 87.5 to 107.9 MHz |
Power |
|
AC Input Power: |
120 VAC, 60 Hz |
Power Consumption: |
Active: 490 WNo Sound: 45 WStandby: 0.1 W |
Physical |
|
Dimensions (W x H x D): |
17.1 x 6.3 x 12.9″ / 435.0 x 160.0 x 328.0 mm |
Weight: |
18.5 lb / 8.4 kg |
Packaging Info |
|
Package Weight: |
21.94 lb |
Box Dimensions (LxWxH): |
20.7 x 16.4 x 9.4″ |
