Description
Specifications
Channel balance at 1 kHz 1 dB
Output voltage at 1 kHz, 5cm/sec 6mV
Channel separation at 1 kHz 26 dB
Frequency response 20 Hz – 20 kHz +2 / 0 dB
Tracking ability at 315 Hz 80 µm
Compliance, dynamic, lateral 15 µm/mN
Cantilever material Aluminium
Stylus type Nude Fine Line diamond
Stylus tip radius r/R 8/40 µm
Coil system Quad-coils with split pole pins
Tracking force, recommended 1.8 g
Tracking angle 20°
Cartridge colour Black/Bronze
Cartridge weight 18 g
Recommended load resistance 47 kΩ
Recommended load capacitance 150-300 pF
