Description
AMPLIFICATION
> Channels: 9
> Amplification Type: Direct Energy
> 185 W/ch (6 ohms, 1 kHz, THD 10 %, 1ch Driven)
> 170 W/ch (8 ohms,1 kHz, THD 1 %, 1ch Driven IEC)
AUDIO FEATURES
> IMAX Enhanced
> Dolby Atmos®, Dolby Surround Upmixer
> DTS:X®, DTS Neural:X® Upmixer
> Reflex Optimizer
> Dolby Atmos Height Virtualizer
> Dolby® TrueHD, Dolby Digital Plus
> DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-ES, DTS Express
> DSD Disc (SACD) Playback via HDMI (2.8 MHz/2 ch, 5.1 ch)
> Digital Quad-Core 32-bit DSP (Cirrus Logic) + Aureus™ floating-point DSP (TI)
> 192 kHz/24-bit D/A Conversion for Hi-Res Audio
> Enhanced Audio Return Channel (eARC) on HDMI Out (Main)
> Advanced MCACC Auto Room Tuning
• Auto Phase Control Plus
• Subwoofer EQ
• Multi-point Standing Wave Control
> Dirac Live® Room Correction
> Advanced Sound Retriever (2ch)
> Advanced Surround Modes
• Classical, Unplugged, Entertainment Show, Drama, Advanced Game, Action, Rock/Pop, Sports, Extended Stereo, Mono Music, Front Stage Surround Advance
VIDEO FEATURES
> Support HDMI 2.1*1 with 8K, VRR (Variable Refresh Rate), ALLM (Auto Low Latency Mode), QFT (Quick Frame transport), DSC (Display Stream Compression), and QMS (Quick Media Switching) pass-through
Supports HDR10+, HDR10, and HLG; 8K/60p (4:2:0/10-bit), 8K/30p
(4:4:4/10-bit, 4:2:2/12-bit), 4K/120p (4:4:4/10-bit, 4:2:2/12-bit), 4K60p
(4:4:4/12-bit) and BT.2020 colour; DeepColour™ (36-bit), “x.v.Colour”,
LipSync, and HDCP 2.3
> Dolby Vision™ Compatible
> Ultra HD Upscaling (4K to 8K, 1080p to 8K/4K)
HOME NETWORK FEATURES
> Works with Alexa supporting multi-room music*2
> Works with OK Google and Chromecast built-in
> DTS Play-Fi with Pioneer Music Control App*3
> Apple AirPlay 2 with Siri Voice Control
> Works with SONOS supporting multiple Sonos Connect control and Volume Pass Through mode
> Amazon Music HD*4, Spotify, TIDAL, and Deezer Hi-Fi Music-Streaming Services Ready*5
> Internet Radio with TuneIn
> Hi-Res Audio File Playback via USB/Network
> Up to 192 kHz/24-bit ALAC*6, AIFF, FLAC, WAV (RIFF) and 11.2 MHz DSD*7
CONVENIENCE FEATURES
> Personal Preset
> Dialog Enhancement
> Dual Band (5 GHz/2.4 GHz) 802.11ac Compliant Wi-Fi® Built-in
> Bluetooth® Wireless Technology Transmitter/Receiver (Version: 4.2, Profile: A2DP 1.2/AVRCP 1.3, Codec: SBC/aptX/aptX HD (TX), SBC/AAC(RX)) Built-in
> Pioneer Remote App*3 Ready for Multi-room Entertainment Control and Network Streaming
> User-Friendly GUI with System Setup Menu
> On-Screen Information for Audio, Video and Network
> Web Setup
> Auto Power Off in HDMI Standby Through
> DAB/FM Tuner 40 Presets
> Sleep Timer
> User-Friendly Simple Remote Control
