Description
ELECTRICAL CHARACTERISTICS
Voltage range for safe continuous operation of YG-3 PSU 160 – 320 V
Power 5750 W
Current 25 А
Power (power supply from the socket) 3680 W
Current (power supply from the socket) 16 А
Self power consumption 1 W – 20 W depends on used features
Сonsumption in case of full power off by button 2 0 W
Neutral pass through resistance < 0.00005 Ohm
Live pass through resistance (high current hi-fi filter without fuse and fuse holder) 0.015 Ohm
Fuse Resistance 0.01 Ohm (with holder), size 5 x 20mm, current 16 A
DC measure range ± 999 mV
Maximum filtering DC value 1.8 V
Maximum on/off delay 60 sec
